CTCP Offset Printing Plate
CTCP Offset Printing Plate is very suitable to UV-CTP(CTpP/CTnP) plate making for its high sensitive speed and excellent dot-reproduction so that it is very fit for commercial top grade color printing and Newpaper printing.which makes the printing enterprise in the production of both economic efficiency at the same time.
Description
Brief Introduction
CTCP Offset Printing Plate is very suitable to UV-CTP(CTpP/CTnP) plate making for its high sensitive speed and excellent dot-reproduction so that it is very fit for commercial top grade color printing and Newpaper printing.which makes the printing enterprise in the production of both economic efficiency at the same time.
Product features
CTCP Offset Printing Plate adopt Excellent coat component to make the plate keep well-proportioned coating apparent, high sensitive speed, fine dot-reproduction,Wide plate making operation latitude and 100000 pressrun.
Specifications
|
Type |
No preheat, positive, excellent chemical-compatibility and high durability. |
|
Applications |
Commercial, newspaper,packaging printing works and so on |
|
Base |
Electrochemically grained and anodized aluminum substrate |
|
Gauge |
0.15mm, 0.20mm,0.24mm,0.30mm and 0.40mm |
|
Coating color |
Blue |
|
Spectral sensitivity |
405 nm |
|
Exposure energy |
45 - 65 mJ/cm2 (based on platesetter settings and resolution) |
|
Resolution |
1% to 99% @ 200 lpi or 20 micron stochastic (based on platesetter settings and capability of image) |
|
Developer |
Good compatible with more than 90% developer brands in the market |
|
Run length |
100,000 impressions unbaked 300,000 plus impressions baked (based on image resolution, print machine,chemical, ink and paper conditions) |
|
Safelight |
Yellow safe-light |
|
Shelf life |
18 months(cool-dry storage,<35℃,40-80%humidity,away from sunlight) |
Certificates
How Does An Offset Plate Work?
During the offset printing process, the ink rollers on the printing press transfer from the image file directly onto a printing plate. Once plated, the image areas are ink receptive and water repellant, and the non-image areas are water receptive and ink repellant. This ensures that the non-image area remains ink free. From the plate, the image is transferred onto a flexible rubber sheet on the press. As the paper passes through the press, between the rubber sheet and the impression cylinder, the image is then transferred onto the paper. This printing process is called "offset" because the ink is offset to the rubber blanket and then to the paper.
FAQ
1.What is a plate in offset printing?
Offset printing plates are what transfer an image from the ink supply to the paper. They are usually made from paper, rubber, plastic, or metal depending on the printing process. Printing plates have an image that is burned onto them. This image will transfer the ink to the paper.
2.Why is the term OFFSET used when referring to these printing plates?
The reason that the term "offset" is used is because the plate will run against another large cylinder and press the image onto it before it presses onto the paper. This is where the term offset comes from because the plate doesn't directly touch the paper. It offsets onto another rubber-coated cylinder before touching the paper.
Hot Tags: CTCP offset printing plate, China CTCP offset printing plate manufacturers, suppliers, factory, Plate Developer, UV CTP Plate, Chemical Developer, Aluminum CTCP Plate, CTP Plates for Offset Printing, Chemical Free CTP Plate
