CTP Offset Printing Plates

CTCP Offset Printing Plate is very suitable to UV-CTP(CTpP/CTnP) plate making for its high sensitive speed and excellent dot-reproduction so that it is very fit for commercial top grade color printing and Newpaper printing.which makes the printing enterprise in the production of both economic efficiency at the same time.

Send Inquiry

Description

Brief Introduction

Product features

CTCP Offset Printing Plate adopt Excellent coat component to make the plate keep well-proportioned coating apparent, high sensitive speed, fine dot-reproduction,wide plate making operation latitude and 100000 pressrun.

china CTCP Offset Printing Plate suppliers

china CTCP Offset Printing Plate manufacturers

wholesale CTCP Offset Printing Plate

Specifications

Type	No preheat, positive, excellent chemical-compatibility and high durability.
Applications	Commercial, newspaper,packaging printing works and so on
Base	Electrochemically grained and anodized aluminum substrate
Gauge	0.15mm, 0.20mm,0.24mm,0.30mm and 0.40mm
Coating color	Blue
Spectral sensitivity	405 nm
Exposure energy	45 - 65 mJ/cm2 (based on platesetter settings and resolution)
Resolution	1% to 99% @ 200 lpi or 20 micron stochastic (based on platesetter settings and capability of image)
Developer	Good compatible with more than 90% developer brands in the market
Run length	100,000 impressions unbaked 300,000 plus impressions baked (based on image resolution, print machine,chemical, ink and paper conditions)
Safelight	Yellow safe-light
Shelf life	18 months(cool-dry storage,<35℃,40-80%humidity,away from sunlight)
